Rugged Mobile Computer
Built for Versatility
PM85

PM85 is designed with durability and practicality, making it suitable for various environments such as enterprise services,
retail, public sector, public transportation, and logistics. It features a sleek, portable 5-inch design with two scanner engine options,
dual speakers with up to 3 W output, and an optional high-capacity 5,800 mAh battery.

PM85
PM85
PM85
PM85
PM85
PM85
1
/
1
PM85
  • Fast and Accurate
    for Any Task
  • Three physical buttons on
    the front, six on the side

    Designed for fast and precise access to major tasks.
    All buttons can be customized using the EmKit solution*
    to optimize settings based on the field environment.
    *Excluding the power key

  • Enhanced User Convenience

    The front display supports touch input even
    when wearing gloves or when wet, improving user convenience.

High-Resolution Scanner for Faster
and More Accurate Work

The white LED enhances readability of color barcodes and improves image capture results, enabling scanning of 1D barcodes with a resolution as fine as 3 mils. Supports OCR (Optical Character Recognition) and Easy Parse options for applications beyond barcodes, such as scanning driver's licenses, boarding passes, and automotive parts parsing. Additionally, its low-power consumption improves battery efficiency.

PM85
PM85
PM85
Simple Yet Powerful
Core Functions

Qualcomm Snapdragon's 8-core 1.8 GHz processor provides maximum computing support in the field. The optional 4 GB RAM and 64 GB ROM storage capacity are sufficient for handling various programs, apps, and personal data.

PM85
  • Drop
    Drop
    1.8 m

    Tested for MIL-STD 810G compliance with a vertical concrete drop test from 1.8 m, instead of the standard 1.5 m drop test.

  • Rain/dust proof
    Rain/dust proof
    IP67

    Passed IP67 test for dust resistance and complete water immersion

  • Tumble
    Tumble
    1000 cycles

    Passed tumble test with 2,000 repeated impacts from a height of 1m

  • Comprehensive Technology
    for User Convenience
  • 3W Dual Speakers

    Supports PTT, VoIP, and speakerphone functions
    with maximum 3W dual speaker output, ensuring clear
    communication even in noisy environments.

  • Integrated LTE Modem
    and Wi-Fi Support

    802.11r enables seamless roaming Wi-Fi use
    without quality loss in any environment.

Specifications
Dimensions
(L x W x D) 		With Standard Battery:
157.6 x 78.0 x 18.9 mm
6.2 x 3.1 x 0.7 in.

With Extended Battery:
157.6 x 78.0 x 23.3 mm
6.2 x 3.1 x 0.9 in.
Weight With Standard Battery:
256 g (9.03 oz.)

With Extended Battery:
315 g (11.11 oz.)
Power Standard Battery: 2,900mAh
Extended Battery: 5,800 mAh
Back-up Battery: 60mAh (10C, Hot-Swap)
Display 5.0 in., IPS panel (1080 x 1920 pixel), FHD
OS Android 8.1, 9
Processor Octa-core 1.8 GHz
Memory and Storage 3 GB / 32 GB or 4 GB / 64 GB (optional)
Communication IEEE 802.11 a/b/g/n/ac/ax-ready/d/h/i/k
/r/v, 1x1 MU-MIMO
LTE (optional)
Bluetooth Class I, ver. 5.0, BLE support
Data Capture Slim 1D/2D scan engine
Drop 1.8 m (6 ft.) multiple drops to concrete,
at room temperature (MIL-STD 810G)

1.5 m (5 ft.) multiple drops to concrete,
across operating temperature range,
(MIL-STD 810G)
Rain/dust Proof IP67
